Brand Name:
Xianfeng
| Model | XF218 CRT Portable Ultrasound Scanner |
| Probe | 80 elements R60, 3.5MHz multi-frequency convex probe |
| Probe automatic identification | |
| Focus | 4 segments dynamic electron focusing |
| double encoder regulations | |
| Frequency Conversion | 2.5MHz/3.0MHz/3.5MHz/4.0MHz /5.0MHz |
| Image processing | Variable aperture |
| dynamic apodization | |
| Dynamic filter | |
| Edge enhancement | |
| Digital space-time filter | |
| 8γ corrections | |
| 16 pesudo colors | |
| Line correlation | |
| Frame correlation | |
| point correlation | |
| linear interpolation | |
| According to the user's pattern style preference, the parameter will be set up automatically and saved ,Boot default this parameter. This default of parameter can aslo be modified in the menue. | |
| Measurement and Note | Distance |
| circumference/area(method of ellipse,method of loci) | |
| heart rate | |
| gestational weeks(BPD,GS,CRL,FL,HL,OFD,TTD,AC) | |
| expected date of confinement and fetus weight,etc. | |
| full-screen character annotation,with report page | |
| Gray scale | 256 levels |
| Gain Control | 8 segments TGC and overall gain can be adjusted respectively |
| Permanment storage | 128 images |
| Cine loop | 256 frames or check one by one |
| Output interface | 2 SVGA video outputs and 2 PAL video outputs |
| Extended Function | Optional USD function,priter fuction,.5MHz trans-vaginal probe, 7.5MHz linear probe, 7.5MHz rectal probe, mobile trolley, video printer, and ulatrasonic image workstation, etc. |
