Product Details:
|
| Product Name: | Portable Veterinary Ultrasound Machine | Type: | Notebook Veterianry Ultrasound |
|---|---|---|---|
| Application: | Veterinary, Animal Hospital, Clinic | Display: | 10" Monitor |
| Display Mode: | B、2B、4B、B/M、M | Key Board: | Standard Key Board And Backlight Key |
| Image Gray Scale: | 256 Gray Scale Level | Probe: | Convex Probe;rectal Probe |
| Probe Socket: | One Probe Sockets | Output Interface: | PAL Video Output,SVGA Video Output,USB |
| High Light: | Xianfeng Notebook Veterinary Ultrasound Machines,Xianfeng Notebook digital ultrasound machines,digital ultrasound scanner rectal |
||
Professional Full Digital 10.4 Notebook Ultrasound Machines For Veterinary Use
Pig,dog,Cat, sheep, horse, cattles,camels, cows and other animals
PW SWINE-HL--head diameter,
PW DOG-GS--sac diameter,
PW DOG-HD---fetal head diameter,
PW DOG-CRL---the diameter of the head to the hips)-,
PW DOG-BD
PW CAT-BD,
PW SHEEP-HD---Head and neck diameter
PW SHEEP-TD---the trunk diameter,
PW EQUINE-CD
PW CATTLE-CRL,
PW CATTLE-HD,
PW CATTLE-HL,
PW CATTLE-TD
Standard Configuration
| Display mode | B;B/B;4B;B+M;M |
| Display size | 10.4inch LED displayer |
| Image multiplying factor |
3.5MHz/R60 convex array probe: x0.8; x1.0, x1.2, x1.5, x1.8, x2.0( 6 modes) |
| E-zoom | Magnify 2 times Magnifying |
| Dynamic range | 0~120db adjustable dynamic range |
| Focus position | Dynamic electron focusing |
|
Image proessing
|
8γcorrections, Point correlation, Frame correlation, Line correlation, Digital filting,Digital edge enhancement and pseudo color processing
According to the user's pattern style preference, the parameter will be set up automatically and saved ,Boot default this parameter. This default of parameter can aslo be modified in the menue.
|
| Gray scale | 256 levels |
| Frequency conversion | 2.5MHz/3.0MHz/3.5MHz/4.0MHz/5.0Mhz 5 periods of frequency conversion Frequency range applies 5.5MHz/6.0MHz/6.5MHz/7.0MHz/7.5MHz can match high frequency probe |
| Measuring function | Distance, circumference/area(method of ellipse,method of loci) ,volume,heart rate, gestational weeks, expected date of confinement and fetus weight,etc. |
| Annotation function | Hospital name;patient’s name, age and gender; Body marks(with probe’s position);Full-screen character annotation;Real-time clock display |
| Puncture guide | 3.5MHz convex array probe can display punture guide in B mode |
| Gain control | 8segments TGC and overall gain can be adjusted respectively |
| Image polarity | Left and right flip; up and down flip |
| Capacity cine loop | Real time display 256 consecutive images which are moemorized successively |
| Image playback | Series playback or check one by one |
| Standard configuration | Ultrasound machine with 3.5Mhz convex array probe and power adapter |
We are an experienced Manufacturer in China, focusing on research development and production in black and white ultrasound and color doppler ultrasound scanner since 2005. We have been doing OEM and ODM more than hundreds of companies and factories over past 15 years.
Our products are affordable , reliable and competent. We sell over 10000 units to all over the world, and repair rate is less than 1%, all production process is strictly exectued with CE and ISO.
