0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital

0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital

ultrasound machine for hospital 0dB

0dB portable ultrasound machine with doppler

ultrasound machine hospital 120dB 0dB

Place of Origin:

Made In China

Brand Name:

Xianfeng

Certification:

CE, ISO

Model Number:

E60

Contact Us
Request A Quote
Product Details
Product Name:
Color Doopler Ultrasound Scanner
Dynamic Rang:
0~120dB Adjustable
Display:
15" LED Screen Displayer
E-zoom:
Magnify 2 Times Of Real Time Image
Depth Display:
≥250mm
Optional Battery:
1.5h Working Hours
Package Size:
470mm(L)* 335mm(W)* 560mm(H)
Weight:
11 KG
Focus Position:
Dynamic Electron Focusing
Type:
Color Doppler
Display Mode:
B,M,BM,BB,PW
Payment & Shipping Terms
Minimum Order Quantity
3-5pcs
Packaging Details
Carton
Delivery Time
1-3 working days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100 Set Per Day
Product Description

Human Portable Doppler Ultrasound Machine for Clinic or Private Hospital

0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 0

Specifications:


*B/2B/4B/M/CFM/PDI/PW
*THI(Tissue Harmonic Imaging)
*Free hand 3D imaging(Optional)
*4D Optional
*Automatic measurement and analysis vascular intima
*Extended imaging
*Compound Imaging
*Multimedia and peripheral devices:Compact Disc-Recordable,USB portable storage device.
*Digital Printer / Video Printer / Laser Printer / Ink-Jet Printer
*Memory Function:Image Storage,Video Storage,Cineloop(≥300 Fram),Solid disk storage space≥120G.
*Puncture guide line:All kinds of probes can register puncture guide line function.
*The puncture guide line Angle adjustable and can be pre-defined.
*Language:Chinese, English, Russian, Spanish, Portuguese, French.






0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 1


0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 2

Ultra Portable,Ultra flexible,Ultra affordable,Ultra durable,Ultra stable


E60 is an economical all-digital portable color doppler ultrasound diagnostic system launched by XianFeng company in 2016.It is compact in appearance and powerful in function.Built-in specialized measurement software package: department of gynaecology and obstetrics, distance,perimeter,area, heart rate, slope, time, the expected date of childbirth, gestational age and fetal weight and so on the many kinds of practical measurement analysis software, stream lined body design, The machine may at any time carry out for field diagnosis, six languages interface, double probe socket, apply to stomach, of department of gynaecology and obstetrics, the urology department, small organs and blood vessels and other parts of the inspection, especially suitable for large hospital bed and clinical examination of the basic medical institutions.Is a high cost - effective instrument.

0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 3





General Specifications
Package Size and weight: 470mm(L)* 335mm(W)* 560mm(H)/ 11 KG
power source: 19V,10A DC IN, Support battery power
Optional battery:10Ah,14.4V.
Battery Operating Time:≥2 hours Standby time: ≥3.5 Hous
Displayer: 15 inch high brightness and high contrast LCD


0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 4

Configuration probe
The configuration probe of the instrument showed as below:


Type Scan model Frequency range   radius of curvature Scan width Scan angle
TC60A Convex 2.0MHz~5.0MHz   R60mm _ 60°
TL40A Linear 5.0MHz~12.0MHz   _ L40mm _
TC10A Cavity 5.0MHz~8.0MHz   R10mm _ 150°
TC20A Micro-convex 2.0MHz~4.0MHz   _ _ 90°





0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 5



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 6



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 7



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 8



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 9

0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 10



We are an experienced Manufacturer in China, focusing on research development and production in black and white ultrasound and color doppler ultrasound scanner since 2005. We have been doing OEM and ODM more than hundreds of companies and factories over past 15 years.
Our products are affordable , reliable and competent. We sell over 10000 units to all over the world, and repair rate is less than 1%, all production process is strictly exectued with CE and ISO.



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 11



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 12



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 13



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 14



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 15



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 16



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 17



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 18



0dB To 120dB Portable Ultrasound Machine With Doppler For Hospital 10



We are an experienced Manufacturer in China, focusing on research development and production in black and white ultrasound and color doppler ultrasound scanner since 2005. We have been doing OEM and ODM more than hundreds of companies and factories over past 15 years.
Our products are affordable , reliable and competent. We sell over 10000 units to all over the world, and repair rate is less than 1%, all production process is strictly exectued with CE and ISO.
